Cylinder Head - E-Street - Assembled - 2.190 / 1.880 in Valves - 290 cc Intake - 110 cc Chamber - 1.550 in Springs - Angle Plug - Aluminum - Big Block Chevy - Each

Edelbrock Cyl Head E-Street BB Chevy Oval Port Complete Single

The Edelbrock #50459 E-Street cylinder 290 Oval Port head is designed for Big-Block applications. The Edelbrock E-Street cylinder head offers American made quality and affordable performance. E-Street cylinder head features as-cast ports and are designed for entry-level street performance applications operating in the idle-to-5500 rpm range. The modern combustion chamber designs improve the combustion process and larger than stock intake and exhaust ports move more air through your engine for improve efficiency. For use on pre-pollution controlled vehicles only.

Additional Information

The #50459 E-Street cylinder 290 Oval Port heads are designed for BBChevy applications. American made quality and affordable performance, These heads feature as-cast ports and are designed for entry-level application

Application Summary

Chevrolet:Big-Block Mark IV:396 (6.6L)/402 (6.6L)/427 (7.0L)/454 (7.4L)/502 (8.2L)

Part Type

Engine Cylinder Head

These additional application notes are supplied by the manufacturer and collated from multiple year ranges. Not all of these notes may apply to every year or every variant. Please contact a StreetFX agent for clarification if required.

• Made In The U.S.A.

Images are supplied by the manufacturer and may be generic. While all efforts are made to provide accurate pictures, there may be differences in the actual product, such as colour, quantity, version, or included components. Please carefully review the description and specifications for details on inclusions or any variations. Some items may be sold individually or in sets, and images may occasionally depict additional products or quantities not included in your purchase. For assistance or clarification, please contact customer support.

Product Details

Product Downloads

#	Document Type	Download
1.	Installation Instructions

Installation guides, warranty details, and other supporting documents are provided by the supplier. In some cases, these files may originate from regions outside your locale, meaning instructions, warranty procedures, and images may not fully align with your specific vehicle or region (e.g., LHD vs. RHD differences, return policies, etc.). If you need clarification, please contact a StreetFX support agent.

Reference Information

Cylinder Head, E-Street, Aluminum, Assembled, 110cc Combustion Chamber, Oval Port, Chevy, Big Block, Each

Are you looking for a set of entry-level street performance heads for your modern street rod, muscle car, or truck? Edelbrock E-Street cylinder heads are just the ticket. These heads feature A356 aluminum castings that are heat-treated to T-6 specs for superior casting strength and quality. Their modern combustion chamber design helps to improve the combustion process and their larger-than-stock intake and exhaust ports help to move more air through your engine. These features improve an engine's efficiency, resulting in more horsepower and torque and improved mileage potential. All Edelbrock E-Street cylinder heads are assembled with manganese bronze valve guides, powder metal interlocking valve seats, and stainless steel one-piece valves with hardened valve tips. Edelbrock E-Street cylinder heads are ideal for entry level street performance engines.
