FLOTEK 180cc Small Block Chevy Cylinder Heads 102-505 Head, 180cc, Assembled, Hydraulic Roller, Straight, Aluminum, Natural, Chevy, Block, Each
FLOTEK 180cc Small Block Chevy Cylinder Heads 102-505 Head, 180cc, Assembled, Hydraulic Roller, Straight, Aluminum, Natural, Chevy, Block, Each
Description
Cylinder Head - Assembled - 2.020 / 1.600 in Valves - 180 cc Intake - 64 cc Chamber - 1.460 in Springs - Straight Plug - Aluminum - Small Block Chevy - Each
Data: v2 - Desc: v4.2 - Upd: 2026-11-08 01:09:43
Features
Images are supplied by the manufacturer and may be generic. While all efforts are made to provide accurate pictures, there may be differences in the actual product, such as colour, quantity, version, or included components. Please carefully review the description and specifications for details on inclusions or any variations. Some items may be sold individually or in sets, and images may occasionally depict additional products or quantities not included in your purchase. For assistance or clarification, please contact customer support.
Specifications
Reference Information
| Reference Data (Provide these details to our support team) | |
|---|---|
| Brand Name/s | Flotek |
| StreetFX SKU | flk102-505 |
| SFX Item ID | 5202640 |
| Accounting SKU | flk-102-505 |
| Manufacturer SKU | 102-505 |
| Manufacturer UPC | 850134007037 |
| Alternative References | FLK-102-505, FTC102505 |
Cylinder Head, 180cc, Assembled, Hydraulic Roller, Straight, Aluminum, Natural, Chevy, Small Block, Each
FLOTEK 180cc small block Chevy cylinder heads are economically priced, out-of-the-box-ready bolt-ons. They include state-of-the-art aluminum casting, 180cc intake ports that are specifically designed for outstanding versatility, and 64cc combustion chambers. Among their standard features: aluminum alloy construction, phosphorous bronze valve guides, high-nickel valve seats—plus ends milled and drilled for accessories, as well as straight or angle spark plugs. Besides the assembled options, these cylinder heads are also offered bare. When choosing the right heads, it's quality, performance, and price that matter most. FLOTEK 180cc Chevy small block heads deliver on all three!
NOTE: This item is not sold as a pair; this is a single cylinder head.
| Product Attributes | |
|---|---|
| Brand | Flotek |
| Manufacturer's Part Number | 102-505 |
| Part Type | Cylinder Heads |
| Product Line | FLOTEK 180cc Small Block Chevy Cylinder Heads |
| UPC | 850134007037 |
| Combustion Chamber Volume (cc) | 64 |
| Intake Runner Volume (cc) | 180cc |
| Exhaust Runner Volume (cc) | 62cc |
| Cylinder Head Style | Assembled |
| Cylinder Head Material | Cast aluminum |
| Camshaft Style | Hydraulic roller |
| Intake Port Shape | Rectangular |
| Intake Valve Diameter (in.) | 2.020 in. |
| CNC-Machined Combustion Chamber | No |
| CNC-Machined Intake Runner | No |
| CNC-Machined Exhaust Runner | No |
| Intake Port Location | Standard |
| Exhaust Port Shape | Square |
| Exhaust Port Location | Standard |
| Spark Plug Style | Straight |
| Intake Valves Included | Yes |
| Exhaust Valves Included | Yes |
| Exhaust Valve Diameter (in.) | 1.600 in. |
| Valve Springs Included | Yes |
| Maximum Valve Lift (in.) | 0.550 in. |
| Outside Diameter of Outer Spring (in.) | 1.460 in. |
| Damper Spring Included | Yes |
| Number of Springs Per Valve | Single |
| Retainers Included | Yes |
| Retainer Material | Chromoly steel |
| Locks Included | Yes |
| Lock Style | 7 degree |
| Valve Stem Seals Included | Yes |
| Valve Stem Seal Style | Positive stop |
| Rocker Arm Studs Included | Yes |
| Rocker Arm Nut Thread Size | 3/8 in.-24 |
| Rocker Arms Included | No |
| Rocker Arm Nuts Included | No |
| Guideplates Included | Yes |
| Guideplate Pushrod Size | 5/16 in. |
| Valve Cover Mounting Style | Center and perimeter bolt |
| Accessory Bolt Holes Drilled | Yes |
| Intake Valve Angle | 23 |
| Exhaust Valve Angle | 23 |
| Valve Guides Included | Yes |
| Valve Guide Material | Manganese bronze |
| Valve Seats Machined | Yes |
| Valve Seat Machine Style | 3-angle |
| Valve Seat Material | Powdered metal |
| Cylinder Head Color | Natural |
| Steam Holes Drilled | No |
| Oiling Style | Through pushrod |
| Machined for O-Ring | No |
| Heat Crossover | No |
| Remanufactured | No |
| Quantity | Sold individually. |
