Piston Ring Set
Wiseco piston ring sets are made specifically to Wiseco?s specifications to provide ultimate performance and sealing with Wiseco?s wide variety of pistons. From compression and sealing to oil control, rings can make or break piston performance, which is why Wiseco rings are developed and tested for race-ready performance.
Engine Piston Ring Set
Wiseco Pro Tru line of pistons utilize a plasma moly âââ¬Ã
âpre-gappedâââ¬Ã ring set for the budget minded consumer. Wiseco Sport compact kits include the high quality NPR XX rings, which are the best quality steel nitrided top rings and napier style 2nd rings. Our late model EFI lineup and several small block Chevy pistons are designed around the our 1.2mm Steel Nitride and napier GFX ring sets. Many of our big block sets utilize a .043 back cut top ring for extra material thickness around the intake valve. *Unless Noted - Rings Sold Individually - Order Specific Quantity Needed*
| 2nd Ring: | 1.2mm Cast Iron / Napier Hook |
| Bore Diameter: | 3.209 |
| Bore: | 81.5mm |
| Category Hierarchy: | Auto>Accessories>Rings |
| Description: | High Performance Piston Rings |
| Engine Type: | ICE |
| File Fit: | No |
| Gapless: | No |
| Industry: | Automotive |
| Oil Ring Thickness: | 2.80 |
| Oil Ring: | 3/16 3-Piece Std Tension |
| Part Number: | wis8150XX |
| Product Type: | Engine Piston Ring Set |
| Second Compression Ring Thickness: | 1.20 |
| Second Ring Facing Material: | Phosphate Coated |
| Second Ring Material: | Cast Iron |
| Size: | .039-.047-2.8mm |
| Third Ring Material: | Stainless Steel |
| Title - Web: | Piston Ring Set - 81.50 mm Bore - 1.00 mm Top / 1.20 mm 2nd / 2.80 mm Oil |
| Title: | Piston Ring Set - 81.50 mm Bore - 1.00 mm Top / 1.20 mm 2nd / 2.80 mm Oil |
| Top Compression Ring Thickness: | 1.00 |
| Top Ring Facing Material: | Gas Nitrided |
| Top Ring Material: | Stainless Steel |
| Top Ring: | 1mm Alloy Steel / Gas Nitrated |
Images are supplied by the manufacturer and may be generic. While all efforts are made to provide accurate pictures, there may be differences in the actual product, such as colour, quantity, version, or included components. Please carefully review the description and specifications for details on inclusions or any variations. Some items may be sold individually or in sets, and images may occasionally depict additional products or quantities not included in your purchase. For assistance or clarification, please contact customer support.
| Additional Application Notes | |
|---|---|
| • B18A1/B1 With B16A VTEC Head | |
| • 2000 and up use 19mm Pins; For Stroker 92.80mm Crank 2000 and up use 19mm Pins | |
| • w/ ABA 2.0L Cylinder Head | |
| • For Stroker 92.80mm Crank and 20Valve Cylinder Head | |
These additional application notes are supplied by the manufacturer and collated from multiple year ranges. Not all of these notes may apply to every year or every variant. Please contact a StreetFX agent for clarification if required.
Piston Rings, Gas Nitrided, 81.50mm Bore, 1.0mm, 1.2mm, 2.8mm Thickness, Single Piston, Set
Wiseco XX piston ring sets are designed for use with Wiseco pistons only. They can be used in cast iron, nickel ceramic plating (Nikasil), boron composite, and Electrofusion bores and feature a stainless steel, 1mm thickness, gas-nitrided, barrel-faced top ring. They also contain an under-hook style, 1.2mm thickness, cast iron, phosphate coated, taper-faced second ring. The oil rings in these XX sets are 3-piece assemblies with 2.8mm thickness, gas-nitrided rails, and a stainless steel, flex-vent spacer. Caution: Wiseco XX 4-stroke rings cannot be used in chrome plated bores; engine damage will occur.
| Product Attributes | |
|---|---|
| Brand | Wiseco |
| Notes | For a single piston. |
| Gapless | No |
| File Fit | No |
| Quantity | Sold as a set. |
| Bore (mm) | 81.500mm |
| Part Type | Piston Rings |
| Bore (in.) | 3.209 in. |
| Gas Ported | No |
| Product Line | Wiseco XX Piston Ring Sets |
| Oil Ring Tension | Standard |
| Oil Ring Included | Yes |
| Oil Ring Material | Chrome plated carbon steel |
| Top Ring Included | Yes |
| Top Ring Material | Steel |
| Oil Ring Thickness | 2.8mm |
| Top Ring Thickness | 1.0mm |
| Second Ring Included | Yes |
| Second Ring Material | Cast iron |
| Second Ring Thickness | 1.2mm |
| Top Ring Facing Material | Gas nitrided |
| Manufacturer's Part Number | 8150XX |
| Second Ring Facing Material | Phosphate coated |
| Manufacturer Attributes | |
|---|---|
| Top Compression Ring Thickness | 1.00 |
| Second Compression Ring Thickness | 1.20 |
| Oil Ring Thickness | 2.80 |
| Bore Diameter | 81.50 |
| Category Hierarchy | Auto>Accessories>Rings |
| Industry | Automotive |
| Second Ring Material | Cast Iron |
| Product Type | Engine Piston Ring Set |
| Top Ring Facing Material | Gas Nitrided |
| Engine Type | ICE |
| File Fit | No |
| Gapless | No |
| Second Ring Facing Material | Phosphate Coated |
| Title | Piston Ring Set - 81.50 mm Bore - 1.00 mm Top / 1.20 mm 2nd / 2.80 mm Oil |
| Title - Web | Piston Ring Set - 81.50 mm Bore - 1.00 mm Top / 1.20 mm 2nd / 2.80 mm Oil |
| Third Ring Material | Stainless Steel |
| Top Ring Material | Stainless Steel |
| Manufacturer Designation | Piston Ring Set - 81.50 mm Bore - 1.00 mm Top / 1.20 mm 2nd / 2.80 mm Oil |
| Product Class | Engine Piston Ring Set |
| Construction/Type | Piston Ring Set - 81.50 mm Bore - 1.00 mm Top / 1.20 mm 2nd / 2.80 mm Oil |
| Vehicle Brief | Wiseco, Piston Ring Set |
| Market Description | Wiseco piston ring sets are made specifically to Wiseco?s specifications to provide ultimate performance and sealing with Wiseco?s wide variety of pistons. From compression and sealing to oil control, rings can make or break piston performance, which is why Wiseco rings are developed and tested for race-ready performance. |
| Wiseco 81.50MM RING SET Ring Shelf Stock | ||||
|---|---|---|---|---|
| Year Range | Make | Model | Submodels | Region |
| 1990-2001 | Acura | Integra | GS, LS, RS, GS-R, Special Edition, Type R | US |
| 1997-2006 | Audi | A4 | Base, Cabriolet | US |
| 1997-2005 | Audi | A4 Quattro | Base, Avant | US |
| 1992-1994 | Audi | S4 | Base | US |
| 1995 | Audi | S6 | Base, Avant | US |
| 2000-2006 | Audi | TT | Base | US |
| 2000-2006 | Audi | TT Quattro | Base, ALMS Edition | US |
| 1999-2000 | Honda | Civic | Si | US |
| 2006-2011 | Honda | Civic | DX, EX, LX, GX, LX-S, EX-L | US |
| 1994-1997 | Honda | Civic del Sol | VTEC | US |
| 1999-2005 | Volkswagen | Beetle | GL, GLS, GLX, Sport, Turbo S | US |
| 1990-1992 | Volkswagen | Corrado | G60 | US |
| 1985-1992 | Volkswagen | Golf | Base, GTI, GL, GT, GTI 16-Valve, GTI 8-Valve | US |
| 2000-2006 | Volkswagen | Golf | GLS, GTI GLS, GTI 337, GTI 1.8T, GTI 20th Anniversary | US |
| 1984-1992 | Volkswagen | Jetta | Base, GL, GLI, Wolfsburg Edition, Carat | US |
| 2000-2005 | Volkswagen | Jetta | GLS, Wolfsburg Edition, GL, GLI | US |
| 1999-2005 | Volkswagen | Passat | GLS, GL, GLS 4 Motion | US |
Please note that this information serves as a fitment guide only. For specific fitment questions or clarifications, please contact us, as manufacturers may introduce variations and modifications during model year or regional revisions. While we strive to provide accurate data, fitment details may vary by region; therefore, compatibility outside the listed region and submodel variant cannot be guaranteed.
| Application Data | |
|---|---|
| Universal | Yes |
| Engine Type | L4 |
This may not be an exhaustive list of compatible vehicles. Please reach out to one of our representatives if you are unsure or do not see your vehicle here.
