Use as a barrier to insulate from any heat source.Designed to provide the best possible heat protection in areas where high temperatures are always present and problematic, Floor & Tunnel Black Shield limits heat transfer on fire walls, transmission tunnels, floor boards, fuel cells and other areas where heat is an issue. Floor & Tunnel Shield II provides excellent light weight thermal protection, acts as a guard against track and road debris, and provides sound deadening as well.Constructed with an embossed 10 mil aluminum face bonded to 1/8" composite glass-fiber core and backed with a high temp super strong pressure sensitive backing, The adhesive side holds past 450°F. Its improved multifaceted modern aluminum surface with high temperature black coating offers improved rigidity and allows for ease of installation. At only 3/16" thick, this product can be shaped and trimmed for a custom fit and is ideal for minimal clearance areas.With a unique and patented finely woven glass-fiber backing, Floor & Tunnel Black Shield is the easiest, most cost effective way to control thermal transfer while protecting expensive components and vehicle occupants from extreme heat situations and sound.Floor & Tunnel Shield Black can be used on any number of surfaces including, metal, aluminum, carbon fiber, plastic, and more. Multiple uses include: fire walls, under hoods, transmission tunnels, floor pans, fuel cells, and exterior under vehicle locations.
Floor And Tunnel Shield II™; 21in. x 48in.; Black;
Universal
DEI Floor and Tunnel Shields II add a new dimension to heat control with minimal clearance needed--only 3/16 in.! Constructed utilizing an embossed aluminum face bonded to a composite fiberglass insulation and backed with an aggressive adhesive that holds past 450 degrees F, these barrier sheets are capable of handling direct temperatures up to 1,750 degrees F. The shields are tough enough for under-vehicle applications. They're also great as a sound barrier, blocking out up to 50 percent of unwanted road noise. DEI Floor and Tunnel Shields II can be cut with tin snips to any shape needed for your application. (Note: Some shields use spray-on adhesive.)
Brand | Design Engineering DEI |
Manufacturer's Part Number | 50552 |
Part Type | Heat Barrier and Sound Deadening Mats |
Product Line | DEI Floor and Tunnel Shields II |
Summit Racing Part Number | DEI-050552 |
UPC | 607078505521 |
Mat Use | Heat barrier |
Length (in.) | 21.000 in. |
Width (in.) | 48.000 in. |
Thickness (in.) | 0.188 |
Installation | Self-adhesive |
Maximum Ambient Temperature (degrees F) | 1,750 degrees F |
Heat Protection Color | Black |
Quantity | Sold individually. |
We do not have any specific fitment data for this part. This could be a generic item or if you need further clarification, please contact us for details to assist us with your compatibility requirements.
Use as a barrier to insulate from any heat source.Designed to provide the best possible heat protection in areas where high temperatures are always present and problematic, Floor & Tunnel Black Shield limits heat transfer on fire walls, transmission tunnels, floor boards, fuel cells and other areas where heat is an issue. Floor & Tunnel Shield II provides excellent light weight thermal protection, acts as a guard against track and road debris, and provides sound deadening as well.Constructed with an embossed 10 mil aluminum face bonded to 1/8" composite glass-fiber core and backed with a high temp super strong pressure sensitive backing, The adhesive side holds past 450°F. Its improved multifaceted modern aluminum surface with high temperature black coating offers improved rigidity and allows for ease of installation. At only 3/16" thick, this product can be shaped and trimmed for a custom fit and is ideal for minimal clearance areas.With a unique and patented finely woven glass-fiber backing, Floor & Tunnel Black Shield is the easiest, most cost effective way to control thermal transfer while protecting expensive components and vehicle occupants from extreme heat situations and sound.Floor & Tunnel Shield Black can be used on any number of surfaces including, metal, aluminum, carbon fiber, plastic, and more. Multiple uses include: fire walls, under hoods, transmission tunnels, floor pans, fuel cells, and exterior under vehicle locations.
Floor And Tunnel Shield II™; 21in. x 48in.; Black;
Universal
DEI Floor and Tunnel Shields II add a new dimension to heat control with minimal clearance needed--only 3/16 in.! Constructed utilizing an embossed aluminum face bonded to a composite fiberglass insulation and backed with an aggressive adhesive that holds past 450 degrees F, these barrier sheets are capable of handling direct temperatures up to 1,750 degrees F. The shields are tough enough for under-vehicle applications. They're also great as a sound barrier, blocking out up to 50 percent of unwanted road noise. DEI Floor and Tunnel Shields II can be cut with tin snips to any shape needed for your application. (Note: Some shields use spray-on adhesive.)
Brand | Design Engineering DEI |
Manufacturer's Part Number | 50552 |
Part Type | Heat Barrier and Sound Deadening Mats |
Product Line | DEI Floor and Tunnel Shields II |
Summit Racing Part Number | DEI-050552 |
UPC | 607078505521 |
Mat Use | Heat barrier |
Length (in.) | 21.000 in. |
Width (in.) | 48.000 in. |
Thickness (in.) | 0.188 |
Installation | Self-adhesive |
Maximum Ambient Temperature (degrees F) | 1,750 degrees F |
Heat Protection Color | Black |
Quantity | Sold individually. |
We do not have any specific fitment data for this part. This could be a generic item or if you need further clarification, please contact us for details to assist us with your compatibility requirements.
DEI Floor and Tunnel Shield II 21in x 48in - 7.0 sq ft
SKU: dei50552
$288.90
or 4 payments of $72.22 with Info
